Plaats van herkomst:
China
Merknaam:
carterberg
Certificering:
IATF16949
Modelnummer:
CB-PLMD-NS1008
Video
Multi-Mount Multi-Line Coupling 3-5 Way Industrial Couplings in Acetal & Brass
Multi-Mount couplings deliver a single, dependable solution for connecting three to five pneumatic or fluid lines simultaneously. Designed for B2B industrial applications, these couplings are available in durable acetal and corrosion-resistant chrome-plated brass. Each unit is keyed to eliminate mismatched connections, ensuring quick, accurate assembly and minimizing downtime. Optional valve configurations allow flexibility in flow control, improving system design adaptability and operational efficiency. Compact, rugged, and engineered for industrial reliability, Multi-Mounts support streamlined installation and maintenance in demanding environments. Ideal for manufacturers, automation systems integrators, and equipment OEMs seeking robust, space-saving multi-line coupling solutions.
SPECIFICATIONS
|
PRESSURE |
|
|
Minimum |
Vacuum |
|
Maximum |
Brass = 500 psi / no. of stations or Acetal = 240 psi / no. of stations |
|
TEMPERATURE:-40°F to 180°F (-40°C to 82°C) |
|
|
MATERIALS |
|
|
Main components |
Acetal or chrome-plated brass |
|
Thumb latch |
Stainless steel |
|
Mounting Plate |
Black anodized aluminum |
|
Valves |
Acetal |
|
Valve spring |
316 stainless steel |
|
External springs and pin |
Stainless steel |
|
O-ring |
Buna-N |
|
TUBING SIZES: 1/8" to 3/8" ID, 3.2mm to 9.5mm ID |
|
|
FEATURES |
BENEFITS |
|
Three to five line connection |
Fast, efficient operation |
|
Separate flow paths |
Pressure and/or vacuum in one coupling |
|
Insert is keyed to body |
Ensures correct line orientation |
|
Acetal or chrome-plated brass |
Maximize design flexibility |
Our Services:
|
1. Customized design, OEM is available. |
|
2. In-time & professional after sales service. |
|
3. Low MOQ, standard package, fast delivery. |
|
4. Special discount and protection are provided to our distributors. |
|
5. As an honest seller, we always use superior raw material, advanced equipments, skilled technicians and strict quality control to ensure our products to be finished in high quality and stable feature. |
